KHAMZABAYEV Zhangali Khamzabaevich – Doctor of Medical Sciences, Professor, Honorary Professor of Karaganda, Semipalatinsk State Medical Academies. Ex-President of the branch of the RNGO “National Medical Association” of the Association of Radiology Specialists. Academician of the Academy of Preventive Medicine. Honorary member of the Georgian, Uzbek Association of Radiologists, Honorary Member of the St. Petersburg Society of Radiologists.
He was born in 1937 in the North Kazakhstan region of the Republic of Kazakhstan. In 1963 he graduated from the Karaganda State Medical Institute. After graduation, he worked for two years at the Research Institute of Occupational Hygiene and Occupational Diseases (Karaganda). In 1965, he entered full-time postgraduate studies in radiology at the A. Vishnevsky Institute of Surgery of the USSR Academy of Medical Sciences. The scientific work was devoted to the study and development of X-ray-angiographic signs of complex combined defects of the tricuspid valve of the heart. Khamzabaev summarized the results of his research in his PhD thesis, which he successfully defended in 1968 at the A. Vishnevsky Institute of Surgery of the USSR Academy of Medical Sciences, Moscow. After completing his postgraduate studies, since 1968, he has been engaged in scientific and practical activities at the A. Syzganov Research Institute of Clinical and Experimental Surgery, serving first as a senior researcher, head of the Department of Radiation Diagnostics, then as deputy director of the Institute for Scientific and Clinical Work. These were the years of active formation and development of cardiac surgery in Kazakhstan, and it was at this time that the director of the Institute, Academician A. N. Syzganov entrusted Zh. Khamzabayev to head the most important diagnostic service of the Institute – the department of radiology with the laboratory of intracardiac research, which he had been continuously leading for 25 years. Professor Zh. Khamzabayev practically implemented the knowledge gained during his years of study in Moscow, actively introduced the latest methods of X-ray angiographic diagnostics into the Kazakh healthcare system. A new, extremely important stage of scientific activity of Zh. Khamzabayev is associated with his studies in 1975 – 1980 in doctoral studies at the A. Bakulev Institute of Cardiovascular Surgery of the USSR Academy of Medical Sciences (Moscow). He described in detail the differential diagnostic criteria and characteristic signs of pathological conditions of the kidneys and their vessels. The obtained data were reflected in the doctoral dissertation of Zh. Khamzabayev, which he successfully defended in Moscow in 1980, at the Scientific Center of Surgery of the Ministry of Health of the Russian Federation, headed by Academician B. Petrovsky (at that time the Minister of Health of the USSR). In 1980, on the initiative of the first radiologist of the Republic of Kazakhstan, who defended his doctoral dissertation on radiation diagnostics, Zh. Khamzabayev, the Republican Center for X-ray Contrast and Angiographic Research Methods was organized for the first time in Kazakhstan. Professor Zh. Khamzabayev was assigned to head the Center. The results of his scientific research were reflected in numerous publications, methodological recommendations, monographs and dissertations carried out under the supervision of Professor Zh. Khamzabaeyev. He held the positions of Chairman of the Scientific Council and Head of the Scientific and Technical Department of the Ministry of Health of the Republic of Kazakhstan in 1988 – 1991; Deputy Director and Head of the Department of Radiation Diagnostics at the Research Institute of Urology in 1994 -1998 ; Head of the Department of Radiation Diagnostics in 1999 – 2002; since 2003 – Head of the Department of Radiology No. 2 of the Medical University of Astana. Zh. Khamzabayev annually organized radiological forums with the participation of major radiologists from other countries, sent doctors from Kazakhstan to study at the European School of Radiologists. On his initiative, all imaging modality (traditional radiology, ultrasound, CT, MRI and interventional radiology) by Order of the Minister of Health of the Republic of Kazakhstan No. 97 “On approval of the nomenclature of medical specialties” (dated 12.02.2007) were merged into a single service “Radiation diagnostics”. Zh. Khamzabayev held a number of international conferences on osteoporosis, for the first time in the republic on the basis of the Research Institute of Traumatology and Orthopedics introduced dual-energy X-ray absorptiometry and ultrasound densitometry for the study of osteoporosis. Professor Zh. Khamzabayev devoted a lot of time to social activities. In 1980 – 2004, he was the chief freelance radiologist of the Ministry of Health of the Republic of Kazakhstan, Chairman of the Scientific Society (President of the Association) of Radiologists of Kazakhstan. He was a member of the editorial boards of a number of scientific journals: “Traumatology and Orthopedics” of the Ministry of Health of the Republic of Kazakhstan; “Radiology – Practice” of the Ministry of Health of the Russian Federation; “Diagnostic and interventional Radiology” of the Ministry of Health of the Russian Federation; “Radiation diagnostics and therapy” of the Ministry of Health of the Russian Federation. Zh. Khamzabayev is the author of 410 scientific works, including 14 monographs, 27 methodological recommendations, 14 inventions. More than 50 PhD and doctoral dissertations have been defended under his leadership. Professor Zh. Khamzabayev was awarded the Order of “Kurmet” by the Decree of the President of the Republic of Kazakhstan No. 23 dated December 16, 2007 for his contribution to the development of healthcare of the Republic of Kazakhstan and international cooperation, for many years of conscientious work. He was awarded the highest award of the Republican Public Association “National Medical Association- the badge “Altyn Dariger“, the Order “Ave Vitae” (posthumously).
The Department of Radiology named after academician Zh.Khamzabayev of Astana Medical University is named in his honor.
SERIK KUANDYKOVICH AKSHULAKOV
Serik Kuandykovich Akshulakov — Kazakh neurosurgeon. Professor, Doctor of Medical Sciences, Academician of the National Academy of Sciences of the Republic of Kazakhstan, Laureate of the State Prize of the Republic of Kazakhstan in the field of science and technology, “Kazakhstan Enbek Yeri”. Chairman of the Board of JSC “National Center of Neurosurgery”, Chief external Neurosurgeon of the Ministry of Health of the Republic of Kazakhstan, President of the Kazakh Association of Neurosurgeons, Editor-in-Chief of the journal “Neurosurgery and Neurology of Kazakhstan”, Honorary Professor of the Research N. N. Burdenko National Medical Research Center of Neurosurgery, member of the Committee on Neurotraumatology of the World Federation of Neurosurgical Societies, member of the Executive Committee of the Asian Congress of Neurosurgeons, member of the Editorial Board of the European Journal of Neurosurgery “Acta Neurochirurgica”, member of the editorial board of the journal “Pediatric Neurosurgery and Neurology” (Russia), member of the editorial board of the journal “Epilepsy. Paroxysmal States” (Russia), honorary member of the Association of Neurosurgeons of Russia, member of the Academia Eurasiana Neurochirurgica.
REVIEW: «Today, interest in the technology of high–intensity focused ultrasound HIFU therapy is growing all over the world – it is a naive high-tech method of treating oncological diseases. Thanks to the efforts and professional activity of Professor Khamzabayev, this method began to be used in our country. This method has proven to be highly effective in treating patients with malignant and benign pathologies of various localizations. And today more than 1000 patients with good results have been treated in Kazakhstan, which determines the importance and necessity of further development of this technology».
KAPRIN ANDREY DMITRIEVICH
Kaprin Andrey Dmitrievich — Russian scientist, Chief oncologist, Doctor of Medical Sciences, Professor, Academician of the Russian Academy of Sciences, corresponding member of the Russian Academy of Education.General Director of the Federal State Budgetary Institution “National Medical Research Radiological Centre” of the Ministry of Health of the Russian Federation, Director of the P. A. Hetsen Moscow Oncology Research Institute – branch of the Federal State Budgetary Institution ” National Medical Research Radiological Centre” of the Ministry of Health of the Russian Federation.
President of the Association of Oncologists of Russia, President of the Association of Directors of Centers and Institutes of Oncology and Radiology of the CIS and Eurasia. Honored Doctor of the Russian Federation, Laureate of the Award of the Government of the Russian Federation in the field of science and technology “For the development, production and introduction of domestic radio sources for contact radiation therapy in oncology”, Chief external oncologist of the Ministry of Health of the Russian Federation, Head of the Department of the Peoples’ Friendship University of Russia.
REVIEW: «The demonstrated equipment is indeed one of the steps towards progress, an amazing find in the treatment of tumors. The procedures are completely painless, without the use of a knife, without complications in the aftermath. Kazakhstan has outstripped Russia in the field of HIFU therapy, this is a breakthrough and an absolute success. Really modern and advanced equipment, which will certainly improve the quality of life of patients. I think the main thing is to take patients who are difficult to help, it will be well combined with various methods of treatment».
NADEZHDA IVANOVNA ROZHKOVA
Nadezhda Ivanovna Rozhkova – Doctor of Medical Sciences, Professor, Honored Scientist of the Russian Federation, Laureate of the USSR Council of Ministers Award, Head of the National Center of Oncology of Reproductive Organs of the P.A. Hertsen Moscow Oncology Research Institute – branch of the Federal State Budgetary Institution “National Medical Research Radiological Centre” of the Ministry of Health of Russia, Professor of the Department of Clinical Mammology, Radiation Diagnostics and Radiation Therapy of the Faculty of Advanced Training of Medical Workers of the Peoples’ Friendship University of Russia. President of the Russian Association of Mammologists.
REVIEW: «First of all, I would like to say that our medicine is now focused on the development of gentle technologies, the so-called technologies of aesthetic mammology, aesthetic medicine, which is aimed at preserving beauty, and in particular, here is your HIFU technique that you use, a focused ultrasound beam that treats tumors and does not allow it to grow. In my opinion, the technique is excellent, which I liked first of all, that in the end there are similar ones, but this is a special device that does not require a special room, special protection of walls, which are usually used for magnetic resonance imaging, for X-ray machines and so on. This is a very big advantage, that is, it can be used in ordinary premises, and by the way, in particular in private centers, because now they have also received their development and this is very good. The technique is good because it allows, firstly, to treat tumors of different localizations, not only the mammary gland, of course the mammary gland is very important and this is my section, but nevertheless, tumors of other organs and systems and this is very important. So, from the words and from the literature, I know that monitoring has been carried out for more than 5 years, these patients have been treated and there are no relapses, this is a very good indicator. And not only that, during the study, despite the fact that the temperature is high, the tumor is being treated, the woman does not feel any discomfort, that is, they ask her in front of me: how does she feel, she says that she is completely normal, she just feels some kind of heat, there is no heat, no burn is happening here. Computer systems are very well developed here, which clearly focus this beam, exactly where the doctor submits the task. You can even treat large tumors, which of course is not desirable, our common medical traditions must be observed here, that is, surgical treatment has been done and so on, but there are some who do not want to do surgery, they start going to healers and this is very sharply negative, because it leads to advanced forms of cancer, and then it is very difficult for us to treat them. Here we can offer a woman an alternative, that is, she can try this method and in general this method is very effective and efficient. The technique, in my opinion, is extremely good and interesting. It corresponds to the main trends in the development of modern X-ray radiology».
SOLOVOV VYACHESLAV ALEXANDROVICH
Solovov Vyacheslav Alexandrovich — oncologist, professor, Doctor of Medical Sciences. Head of the Department of Interventional methods of Diagnosis and Treatment. Full member of the International Association of Therapeutic Ultrasound, corresponding member of the American Association of Radiologists, Full member of the Association of European and American Medical Oncologists, Awarded the Diploma of the Minister of Health of the Republic of Kazakhstan in 2011 for his contribution to the development of healthcare in Kazakhstan.
REVIEW: «Kazakhstan is very lucky – after all, with the purchase of such a device, they have become one step closer to quality treatment. Ahead of all other CIS countries, Kazakhstani entrepreneurs have taken up the treatment of cancer patients, introducing the latest developments in the world in the fight against cancer. This is a serious step, and we, for our part, will provide the necessary scientific assistance and wish prosperity and successful results».
ABLATION (HIFU) IN THE TREATMENT OF CANCER PATIENTS
V.A.Solovov, N.Zh.Khamzabaev, V.V. Benberin
High-intensity Focused Ultrasound Therapy (HIFU) is a rapidly developing technology that combines the latest developments in medical imaging and high-tech treatment. HIFU therapy is distinguished by a wide range of applications in medicine, high treatment efficiency, minimal number of complications, non-invasiveness, short recovery time. This review provides literature data on the use of ultrasound ablation in the treatment of cancer patients.
High-intensity focused ultrasound ablation (HIFU) is a rapidly developing technology that includes modern developments in medical imaging and minimally invasive therapy under visual control. HIFU therapy has high treatment efficiency and accuracy, the absence of ionizing radiation, the possibility of treating cancer at all stages (radical in the early stages, palliative in the advanced ones), the absence of anesthesia, a short rehabilitation period, the possibility of treating cancer of many localizations – prostate, pancreas, liver, kidneys, bones, soft tissues, bladder, retroperitoneal space, mammary and thyroid glands, uterus. The method is not limited only to ultrasound ablation of neoplasms, and is also widely used for palliative purposes to relieve pain of tumor genesis.
The first scientific work devoted to HIFU was published in the 20s of the XX century, in which American researchers Wood and Loomis described the effects of focused ultrasound on unicellular organisms and tissue samples of fish [41]. In 1956, Professor A.K. Burov first proposed the idea of using focused high-frequency sound waves in the treatment of malignant tumors [42]. A group of researchers from the Illinois Institute of Technology, USA, in 1957 described in detail the effects of focused ultrasound on animal tissues, thereby laying the theoretical foundations for the introduction of HIFU into clinical practice. The observations published in 1960 by Soviet scientists L. D. Rosenberg and M. G. Sirotyuk on the emission of sound into a liquid in the presence of cavitation, as well as the development of devices for measuring ultrasonic fields in media in the presence of cavitation, made it possible to make a big step in the development of the method and a general understanding of the physics of ultrasound effects on tissues [52]. The appearance of imaging methods in the doctor’s arsenal made it possible to monitor changes in tissues exposed to HIFU and evaluate the therapeutic effect in real time. The clinical experience accumulated over many years demonstrates the possibility of using high-intensity focused ultrasound ablation in oncological practice, allowed us to evaluate the effectiveness of the technology and side effects, as well as morphological changes in tissues. The principle of HIFU therapy is based on the effect of high-frequency sound waves concentrated in a given focus, generated by a piezoelectric element [40]. Ultrasound waves have a pronounced ability to have a focal effect on tissues, unlike scattered waves used, for example, in ultrasound diagnostics. The cytolytic effect is achieved due to a cascade of processes caused by mechanical and thermal effects of ultrasound. Due to the absorption of acoustic energy by tissues, their local heating occurs up to 850C, and as a result, coagulation necrosis occurs. The most important mechanical factor of the impact is the effect of cavitation – the appearance of microscopic gas cavities, microbubbles in the tissues, during the collapse of which a shock wave is formed, developing a pressure in the microenvironment up to 30,000 Bar, which ensures the physical destruction of cells [43, 44]. The great advantage of HIFU therapy is the ability to monitor the ablation zone using diagnostic ultrasound in real time. In addition to ultrasound navigation, MRI control is also used, which provides better visualization, but has the traditional disadvantages of nuclear magnetic resonance: the high cost of the method and spatial limitations [45, 46].
Therapy of pain syndrome of cancer patients
Pain syndrome is noted in 80% of cancer patients, it is often severe and requires treatment with analgesics [19]. Despite the progress made in the treatment of pain in such patients, modern therapies have limited effectiveness, which significantly worsens the quality of life of patients [18, 19].
Different pain management strategies can be implemented depending on the type and stage of cancer. In general, currently, the standard of pain treatment in cancer patients is treatment with nonsteroidal anti-inflammatory drugs and opioids in accordance with the three-step pain scale of the World Health Organization (WHO) [32]. Morphine is the most commonly used opioid; however, its effectiveness is limited by side effects such as sedation, nausea, constipation and respiratory depression; variability in patient response [22]. In addition, the use and effectiveness of opioids is limited by hyperalgesia caused by them, stimulation of tumor growth and neoangiogenesis and the development of opioid dependence [9, 19, 22, 28].
In the case of insufficient analgesic effect, interventional techniques such as regional anesthesia, nerve blockade and neuroaxial neurolysis, as well as implantable drug delivery systems, can be used in drug treatment. Repeated treatment sessions are often necessary [3]. In some cases, neurosurgical operations are performed to modulate or destroy structures involved in the transmission and perception of pain [29].
Treatments such as radiation therapy, chemotherapy, and surgery can eliminate pain, but they can also make it worse. In addition, neuropathy caused by chemotherapy is observed in 30-70% of patients and often leads to a reduction in the dose of the drug to a suboptimal level and, as a consequence, to inadequate treatment [19].
HIFU therapy of bone metastases
Bone metastases are one of the most common causes of pain in cancer patients [21]. Regardless of the cause – mechanical or biochemical – the pain can be severe and difficult to control.
Currently, the standard of treatment for metastatic bone pain is radiation therapy. However, this method is not effective enough in many cases. It is reported that 20-30% of patients do not experience adequate anesthesia, and a significant number of them have recurrent pain. At the same time, there is a limitation of repeated treatment due to the significant toxic effects of radiation [30]. In most cases, radiation therapy has a long latency period, up to 4 weeks, necessary to achieve a palliative effect in patients with severe pain syndrome [13, 17].
In the last decade, HIFU therapy has been approved for the treatment of bone metastases in the USA, Europe, Asia, Canada, Israel and Russia. In 2015, a consensus was reached by recognized international experts on the effectiveness of the treatment of painful bone metastases by HIFU therapy [12]. There are several mechanisms for pain relief achieved with HIFU. Periosteal denervation caused by heating has the greatest effect on pain relief [4]. Coagulation necrosis of the tumor can lead to a decrease in pain due to a decrease in the size of the tumor [4]. Moreover, the removal of tumor cells reduces the local release of chemical mediators and the degree of osteolysis caused by osteoclasts [37]. Also, HIFU therapy causes bone remodeling with rapid recovery of thermal damage and accelerated sclerosis in osteolytic metastases [2, 5, 8, 14,15, 24,].
Clinical studies of HIFU therapy were conducted under the control of ultrasound [16] and MRI [4, 5, 8, 11, 14, 17, 24], which have demonstrated the high effectiveness of the method for relieving pain syndrome in patients with bone metastases.
Currently, HIFU is recommended as a second-line treatment after radiation therapy to relieve pain associated with bone metastases other than the bones of the skull and spine. HIFU can be used to treat metastases of the ribs, sternum, pelvic bones, shoulder girdle, back of the lumbar and sacral vertebrae and limbs [12].
HIFU can be used as a first-line treatment when radiation therapy is contraindicated or the patient refuses to receive it. The main goal of treatment is analgesia, although local control of the tumor can be assessed as a secondary goal [11]. In 2013, a randomized placebo-controlled blind multicenter HIFU study was conducted with 147 patients. Pain reduction was achieved in 64.3% of patients, and about 20% of them achieved complete anesthesia. In two thirds of patients, the response was achieved within 3 days [13]. In the study Bertrand et al. [1] it is reported that all patients had a significant reduction in pain a week after HIFU. In addition, the study noted that a complete tumor response was achieved in 37.5% of patients, a partial response in 50%. In another study, the authors show that in 53% of patients with bone metastases, pain relief occurred within 30 days after treatment [10].
HIFU has advantages for relieving pain syndrome in patients with bone metastases. There are no restrictions based on the type of bone injury (osteolytic or osteoblastic) associated with previous radiation therapy or chemotherapy. In addition, the number of sessions that a patient can undergo in cases of relapse of pain is not limited [4, 13, 17]. Moreover, HIFU can be performed simultaneously with chemotherapy [23]. Pain syndrome is stopped in 60-100% of patients, is achieved within 3 days and lasts more than 3 months [4, 8, 13, 17, 24].
HIFU Pancreatic Cancer Therapy
Pancreatic adenocarcinoma accounts for more than 95% of all pancreatic cancers and is currently the fourth leading cause of cancer death. Pancreatic cancer is most often detected at an inoperable stage, and only 20% of patients are operable at diagnosis [7]. In addition, after surgery, the frequency of local-regional relapses is high, which explains the high mortality rate. 60-90 % of patients with pancreatic cancer have a pronounced pain syndrome [49].
In a recent meta-analysis, it was shown that the use of HIFU relieves pain syndrome in most patients with pancreatic adenocarcinoma. The mechanisms of action are not fully understood, but they can be based on thermal damage to the nerve endings of the tumor, inactivation of the fibers of the abdominal plexus and a decrease in the volume of the tumor, which leads to a decrease in mechanical pressure on nerve structures. It is noted that HIFU therapy is effective in relieving pain syndrome in 80-100% of patients with pancreatic cancer [7]. The immediate analgesic effect is significant, since most patients can stop taking opioid medications. In another study, the analgesic effect of HIFU therapy was noted for a longer period – up to 17 months [34]. In the study Marinova et al. [20] it is reported that 85% of patients after HIFU achieved long-term relief of pain syndrome, while 50% of patients after treatment did not need any additional analgesics.
In addition to the analgesic effect, a number of authors note local tumor control. It was also noted that pain relief occurs even in the absence of a tumor reaction. Xiong and co-authors [35] inform that the analgesic effect was achieved in 88.0% and 76.2% of patients in both the presence and absence of an objective tumor response, respectively. Similar results were obtained by Zhao et al. [39]: pain relief was achieved in 88.2% of patients with a tumor response in 35.0% of patients with stable or progressive disease. In the work of Ning et al. [25] the results of treatment with HIFU therapy in 523 patients with unresectable pancreatic tumors were published. The authors noted that the majority of patients had complete or partial relief of pain syndrome, as well as an increase in patient survival compared with chemotherapy.
In addition to pain relief, HIFU therapy increases patient survival. A significant increase in survival was observed in an uncontrolled series of cases of patients with pancreatic adenocarcinoma of stage III and IV, who underwent HIFU in conjunction with chemotherapy. The maximum survival after treatment was 3.4 years [31].
HIFU Prostate Cancer Therapy
The main advantages of HIFU in the treatment of prostate cancer are the non-invasiveness of the method, the absence of ionizing radiation, the possibility of use in patients with severe concomitant pathology, good medium and long-term oncological results, the possibility of repeated procedures in one patient and a low percentage of perioperative complications [46]. In addition, an important factor of reproducibility of the method is its low cost and short learning curve of the operator. Chiang P. H., Liu Y. Y. presented a large retrospective study involving 492 patients comparing the main surgical methods of prostate cancer treatment – radical prostatectomy, brachytherapy, cryodestruction and HIFU. The average follow-up period was 3 years. The highest frequency of biochemical relapse after treatment (54.7%) was observed in the brachytherapy group, especially in patients of intermediate and high risk according to D’Amico. The HIFU group demonstrated not only good oncological results, but also satisfactory urine retention function (according to the IPSS questionnaire), and the absence of erectile dysfunction in 65.5% of patients a year after treatment [47]. In 2015, Stephanie Guillaumier and co-authors presented a multicenter study of 5-year results after focal HIFU therapy for localized prostate cancer. The analysis included 625 patients who underwent HIFU therapy, and their rates of relapse-free, metastatic, cancer-specific, and overall survival were 88%, 98%, 100% and 99%. In the same year 2015, a group of British and American researchers led by Mark Emberton published data from a multicenter study involving 754 patients. The average follow-up period was 46 months, while 70% of patients had no biochemical relapse [48]. Mutsuo Hayashi et al. A study of 224 patients with localized prostate cancer was published. There were no prostate cancer deaths among the studied patients. 7-year relapse-free survival among all patients was 75%, and five-year relapse-free survival for patients of low, intermediate and high risk groups was 98%, 84% and 59%, respectively [49]. In 2013, German scientists Ganzer R., Fritsche H. M. described their fourteen-year experience of using HIFU therapy in the treatment of localized prostate cancer. 538 patients were examined, and the average follow-up period was 8.1 years. Overall survival after 5 years was 81%, after 10 years – 61%, cancer-specific survival was 96.7% (death from prostate cancer in 18 patients) [50]. Samara scientists in 2015 presented 7-year results of the use of HIFU in 976 patients with localized prostate cancer. The Kaplan-Meyer relapse-free survival in the entire group of patients was 79.2%, in the low– and medium-risk groups according to D’Amico – 93.9% and 91.8%, respectively [50].
HIFU therapy for other cancers that cause pain syndrome
The possibility of using HIFU therapy to relieve pain in patients with other malignant neoplasms was analyzed. These studies should be taken into account and considered as an option for conducting therapy for pain relief.
Neuroendocrine tumors of the pancreas (NPJ) were effectively treated with HIFU under ultrasound control [6, 26, 27]. Although NTTP are not as aggressive as pancreatic adenocarcinoma, they are often diagnosed late, when most patients have abdominal pain, dyspepsia and insomnia due to pain. The majority of patients noted the disappearance of pain after therapy.
A study was published evaluating HIFU therapy under ultrasound control for the treatment of inoperable hepatocellular carcinoma in 145 patients. Relief of pain syndrome was achieved in 84.8% of patients. In addition, appetite improved in 76.3% of patients and the general well-being of patients. At the same time, survival was higher in patients in the group where HIFU treatment was carried out for the entire volume of the tumor [36].
A group of 83 patients with gastric cancer metastases to abdominal lymph nodes who received chemotherapy in combination with HIFU was compared with 102 patients who were treated with chemotherapy alone. 56 out of 83 patients in the chemotherapy and HIFU group and 64 out of 102 patients in the chemotherapy-only group experienced pain before treatment. Partial or complete pain relief was achieved in 75% of patients in the group receiving HIFU together with chemotherapy and in 51.6% of patients in the group receiving only chemotherapy [38].
Encouraging results were observed in patients with advanced stages of malignant neoplasms of the kidneys. In one study, 13 patients underwent HIFU therapy. After treatment, 90% of patients reported a reduction in pain. In 2 patients, the stage of cancer was lowered, which allowed for radical nephrectomy [33].
The results of these studies are promising, not only because pain relief was successful in most of the treated patients, but also because HIFU therapy demonstrated stable local control of the tumor or led to a decrease in the stage. The noninvasiveness of HIFU therapy makes this treatment available to patients with concomitant diseases who cannot undergo surgery.
Conclusion:
Summarizing the above, it should be noted that HIFU therapy will play an important role in the treatment of cancer patients. Having significant advantages, such as non-invasiveness, high efficiency and accuracy of treatment, rapid and long-term relief of pain syndrome, the minimum number of complications allows the use of HIFU for the treatment of malignant neoplasms of various localizations and stages. In addition, HIFU therapy can be combined with all other types of anti-cancer treatment. HIFU therapy significantly improves the quality of life and leads to an increase in the survival rate of cancer patients.
Brown MR, Farquhar-Smith P, Williams JE, ter Haar G, deSouza NM. The use of high-intensity focused ultrasound as a novel treatment for painful conditions: a description and narrative review of the literature. Br J Anaesth 2015;115(4):520–530.
Candido KD, Kusper TM, Knezevic NN. New cancer pain treatment options. Curr Pain Headache Rep 2017;21(2):12.
Catane R, Beck A, Inbar Y, et al. MR-guided focused ultra-sound surgery (MRgFUS) for the palliation of pain in patients with bone metastases: preliminary clinical experience. Ann Oncol 2007;18(1):163–167.
Chan M, Dennis K, Huang Y, et al. Magnetic resonance-guided high-intensity-focused ultrasound for palliation of painful skeletal metastases: a pilot study. Technol Cancer Res Treat 2017;16(5):570–576.
Chen Q, Zhu X, Chen Q, Wang K, Meng Z. Unresectable giant pancreatic neuroendocrine tumor effectively treated by high-intensity focused ultrasound: a case report and review of the literature. Pancreatology 2013;13(6):634–638.
Dababou S, Marrocchio C, Rosenberg J, et al. A meta-analysis of palliative treatment of pancreatic cancer with high intensity focused ultrasound. J Ther Ultrasound 2017;5(1):9.
Gianfelice D, Gupta C, Kucharczyk W, Bret P, Havill D, Clemons M. Palliative treatment of painful bone metastases with MR imaging–guided focused ultrasound. Radiology 2008;249(1):355–363.
Gupta K, Kshirsagar S, Chang L, et al. Morphine stimulates angiogenesis by activating proangiogenic and survival- promoting signaling and promotes breast tumor growth. Cancer Res 2002;62(15):4491–4498.
Huisman M, ter Haar G, Napoli A, et al. International consensus on use of focused ultrasound for painful bone metastases: current status and future directions. Int J Hy-perthermia 2015;31(3):251–259.
Huisman M, ter Haar G, Napoli A, Hananel A, Ghanouni P, Lovey G, et al. International consensus on use of focused ultrasound for painful bone metastases: current status and future directions. Int J Hyperth. 2015;31:251–259. doi: 10.3109/02656736.2014.995237.
Hurwitz MD, Ghanouni P, Kanaev SV, et al. Magnetic resonance-guided focused ultrasound for patients with painful bone metastases: phase III trial results. J Natl Cancer Inst 2014;106(5):dju082.
Joo B, Park MS, Lee SH, et al. Pain palliation in patients with bone metastases using magnetic resonance-guided focused ultrasound with conformal bone system: a preliminary report. Yonsei Med J 2015;56(2):503–509.
Khokhlova TD, Hwang JH. HIFU for palliative treatment of pancreatic cancer. J Gastrointest Oncol 2011;2(3): 175–184.
Li C, Zhang W, Fan W, Huang J, Zhang F, Wu P. Noninvasive treatment of malignant bone tumors using high-intensity focused ultrasound. Cancer 2010;116(16):3934–3942.
Liberman B, Gianfelice D, Inbar Y, et al. Pain palliation in patients with bone metastases using MR-guided focused ultrasound surgery: a multicenter study. Ann Surg Oncol 2009;16(1):140–146.
Mantyh PW, Clohisy DR, Koltzenburg M, Hunt SP. Molecular mechanisms of cancer pain. Nat Rev Cancer 2002;2(3):201–209.
Mantyh PW. Cancer pain and its impact on diagnosis, survival and quality of life. Nat Rev Neurosci 2006;7(10):797–809.
Marinova M, Wilhelm-Buchstab T, Strunk H. Advanced Pancreatic Cancer: High-Intensity Focused Ultrasound (HIFU) and Other Local Ablative Therapies. Rofo. 2019 Mar;191(3):216-227. doi: 10.1055/a-0820-5564. Epub 2019 Jan 31.
Mercadante S. Malignant bone pain: pathophysiology and treatment. Pain 1997;69(1-2):1–18.
Mercadante S. Managing difficult pain conditions in the cancer patient. Curr Pain Headache Rep 2014;18(2):395.
Meyer J, Pfeffer R, Kanaev S, et al. MR-guided focused ultrasound for painful bone metastases: safety when combined with chemotherapy. J Ther Ultrasound 2015;3(suppl 1):O50.
Napoli A, Anzidei M, Marincola BC, et al. Primary pain palliation and local tumor control in bone metastases treated with magnetic resonance-guided focused ultrasound. Invest Radiol 2013;48(6):351–358.
Ning Z, Xie J, Chen Q, Zhang C, Xu L, Song L, Meng Z. HIFU is safe, effective, and feasible in pancreatic cancer patients: a monocentric retrospective study among 523 patients. Onco Targets Ther. 2019 Feb 1;12:1021-1029. doi: 10.2147/OTT.S185424.
Orgera G, Krokidis M, Monfardini L, et al. High intensity focused ultrasound ablation of pancreatic neuroendocrine tumours: report of two cases. Cardiovasc Intervent Radiol 2011;34(2):419–423.
Orsi F, Zhang L, Arnone P, et al. High-intensity focused ultrasound ablation: effective and safe therapy for solid tumors in difficult locations. AJR Am J Roentgenol 2010;195(3):W245–W252.
Pinkerton R, Hardy JR. Opioid addiction and misuse in adult and adolescent patients with cancer. Intern Med J 2017;47(6):632–636.
Raslan AM, Burchiel KJ. Neurosurgical advances in cancer pain management. Curr Pain Headache Rep 2010;14(6):477–482.
Saarto T, Janes R, Tenhunen M, Kouri M. Palliative radiotherapy in the treatment of skeletal metastases. Eur J Pain 2002;6(5):323–330.
guided high intensity focused ultrasound for malignant tumors: the Spanish experience of survival advantage in stage III and IV pancreatic cancer. Ultrason Sonochem 2015;27:703–706
Organization website. www.who.int/cancer/palliative/painladder/ en/. Published 2014. Accessed May 1, 2017.
Wu F, Wang ZB, Chen WZ, Bai J, Zhu H, Qiao TY. Preliminary experience using high intensity focused ultrasound for the treatment of patients with advanced stage renal malignancy. J Urol 2003;170(6 Pt 1):2237–2240.
Wu F, Wang ZB, Zhu H, et al. Feasibility of US-guided high-intensity focused ultrasound treatment in patients with advanced pancreatic cancer: initial experience. Radiology 2005;236(3):1034–1040.
Xiong LL, He CJ, Yao SS, et al. The preliminary clinical results of the treatment for advanced pancreatic carcinoma by high intensity focused ultrasound. Chin J Gen Surg 2001;16(6):345–347.
Xu G, Luo G, He L, et al. Follow-up of high-intensity focused ultrasound treatment for patients with hepatocellular carcinoma. Ultrasound Med Biol 2011;37(12):1993–1999.
Yeo SY, Elevelt A, Donato K, et al. Bone metastasis treatment using magnetic resonance-guided high intensity focused ultrasound. Bone 2015;81:513–523.
Zhang M, Liu L, Wang J, et al. Effects of high-intensity focused ultrasound for treatment of abdominal lymph node metastasis from gastric cancer. J Ultrasound Med 2015;34(3):435–440.
Zhao H, Yang G, Wang D, et al. Concurrent gemcitabine and high-intensity focused ultrasound therapy in patients with locally advanced pancreatic cancer. Anticancer Drugs 2010;21(4):447–452.
HIFU-терапии на современном этапе. Research’n Practical Medicine Journal. – 2016. – Т. 3. – №. 3.
effects of high frequency soundwaves of great intensity. Phil. Mag. – 1927. – 4: С. 417.
А.К. High-intensity ultrasonic vibrations for action on animal and human malignant tumours. Dokl. Akad. Nauk USSR. – 1956. – 106. С. 239–41.
UltrasoundMedBiol. 1994;20:205–18.
медико-хирургического Центра им. Н.И. Пирогова. – 2008. – 3 (2). – С. 77–82.
Changes in ultrasonic image of tissue damaged by high intensity ultrasound in vivo. J. Acoustic Soc. Am. – 1998. – 103. – С. 2869.
JP., Moreau JL. et al. High-intensity focused ultrasound in prostate cancer; a systematic literature review of the French Association of Urology. BJU Int 2008; 101: 1205-13.
R., Fritsche H. M., Brandtner A.et al. Fourteen-year oncological and functional outcomes of high-intensity focused ultrasound in localized prostate cancer. BJU Int.–2013. –112(3). –С. 322-9.
Reviews of academicians and professors
KHAMZABAYEV ZHANGALI KHAMZABAEVICH
KHAMZABAYEV Zhangali Khamzabaevich – Doctor of Medical Sciences, Professor, Honorary Professor of Karaganda, Semipalatinsk State Medical Academies. Ex-President of the branch of the RNGO “National Medical Association” of the Association of Radiology Specialists. Academician of the Academy of Preventive Medicine. Honorary member of the Georgian, Uzbek Association of Radiologists, Honorary Member of the St. Petersburg Society of Radiologists.
He was born in 1937 in the North Kazakhstan region of the Republic of Kazakhstan. In 1963 he graduated from the Karaganda State Medical Institute. After graduation, he worked for two years at the Research Institute of Occupational Hygiene and Occupational Diseases (Karaganda). In 1965, he entered full-time postgraduate studies in radiology at the A. Vishnevsky Institute of Surgery of the USSR Academy of Medical Sciences. The scientific work was devoted to the study and development of X-ray-angiographic signs of complex combined defects of the tricuspid valve of the heart. Khamzabaev summarized the results of his research in his PhD thesis, which he successfully defended in 1968 at the A. Vishnevsky Institute of Surgery of the USSR Academy of Medical Sciences, Moscow. After completing his postgraduate studies, since 1968, he has been engaged in scientific and practical activities at the A. Syzganov Research Institute of Clinical and Experimental Surgery, serving first as a senior researcher, head of the Department of Radiation Diagnostics, then as deputy director of the Institute for Scientific and Clinical Work. These were the years of active formation and development of cardiac surgery in Kazakhstan, and it was at this time that the director of the Institute, Academician A. N. Syzganov entrusted Zh. Khamzabayev to head the most important diagnostic service of the Institute – the department of radiology with the laboratory of intracardiac research, which he had been continuously leading for 25 years. Professor Zh. Khamzabayev practically implemented the knowledge gained during his years of study in Moscow, actively introduced the latest methods of X-ray angiographic diagnostics into the Kazakh healthcare system. A new, extremely important stage of scientific activity of Zh. Khamzabayev is associated with his studies in 1975 – 1980 in doctoral studies at the A. Bakulev Institute of Cardiovascular Surgery of the USSR Academy of Medical Sciences (Moscow). He described in detail the differential diagnostic criteria and characteristic signs of pathological conditions of the kidneys and their vessels. The obtained data were reflected in the doctoral dissertation of Zh. Khamzabayev, which he successfully defended in Moscow in 1980, at the Scientific Center of Surgery of the Ministry of Health of the Russian Federation, headed by Academician B. Petrovsky (at that time the Minister of Health of the USSR). In 1980, on the initiative of the first radiologist of the Republic of Kazakhstan, who defended his doctoral dissertation on radiation diagnostics, Zh. Khamzabayev, the Republican Center for X-ray Contrast and Angiographic Research Methods was organized for the first time in Kazakhstan. Professor Zh. Khamzabayev was assigned to head the Center. The results of his scientific research were reflected in numerous publications, methodological recommendations, monographs and dissertations carried out under the supervision of Professor Zh. Khamzabaeyev. He held the positions of Chairman of the Scientific Council and Head of the Scientific and Technical Department of the Ministry of Health of the Republic of Kazakhstan in 1988 – 1991; Deputy Director and Head of the Department of Radiation Diagnostics at the Research Institute of Urology in 1994 -1998 ; Head of the Department of Radiation Diagnostics in 1999 – 2002; since 2003 – Head of the Department of Radiology No. 2 of the Medical University of Astana. Zh. Khamzabayev annually organized radiological forums with the participation of major radiologists from other countries, sent doctors from Kazakhstan to study at the European School of Radiologists. On his initiative, all imaging modality (traditional radiology, ultrasound, CT, MRI and interventional radiology) by Order of the Minister of Health of the Republic of Kazakhstan No. 97 “On approval of the nomenclature of medical specialties” (dated 12.02.2007) were merged into a single service “Radiation diagnostics”. Zh. Khamzabayev held a number of international conferences on osteoporosis, for the first time in the republic on the basis of the Research Institute of Traumatology and Orthopedics introduced dual-energy X-ray absorptiometry and ultrasound densitometry for the study of osteoporosis. Professor Zh. Khamzabayev devoted a lot of time to social activities. In 1980 – 2004, he was the chief freelance radiologist of the Ministry of Health of the Republic of Kazakhstan, Chairman of the Scientific Society (President of the Association) of Radiologists of Kazakhstan. He was a member of the editorial boards of a number of scientific journals: “Traumatology and Orthopedics” of the Ministry of Health of the Republic of Kazakhstan; “Radiology – Practice” of the Ministry of Health of the Russian Federation; “Diagnostic and interventional Radiology” of the Ministry of Health of the Russian Federation; “Radiation diagnostics and therapy” of the Ministry of Health of the Russian Federation. Zh. Khamzabayev is the author of 410 scientific works, including 14 monographs, 27 methodological recommendations, 14 inventions. More than 50 PhD and doctoral dissertations have been defended under his leadership. Professor Zh. Khamzabayev was awarded the Order of “Kurmet” by the Decree of the President of the Republic of Kazakhstan No. 23 dated December 16, 2007 for his contribution to the development of healthcare of the Republic of Kazakhstan and international cooperation, for many years of conscientious work. He was awarded the highest award of the Republican Public Association “National Medical Association- the badge “Altyn Dariger“, the Order “Ave Vitae” (posthumously).
The Department of Radiology named after academician Zh.Khamzabayev of Astana Medical University is named in his honor.
SERIK KUANDYKOVICH AKSHULAKOV
Serik Kuandykovich Akshulakov — Kazakh neurosurgeon. Professor, Doctor of Medical Sciences, Academician of the National Academy of Sciences of the Republic of Kazakhstan, Laureate of the State Prize of the Republic of Kazakhstan in the field of science and technology, “Kazakhstan Enbek Yeri”. Chairman of the Board of JSC “National Center of Neurosurgery”, Chief external Neurosurgeon of the Ministry of Health of the Republic of Kazakhstan, President of the Kazakh Association of Neurosurgeons, Editor-in-Chief of the journal “Neurosurgery and Neurology of Kazakhstan”, Honorary Professor of the Research N. N. Burdenko National Medical Research Center of Neurosurgery, member of the Committee on Neurotraumatology of the World Federation of Neurosurgical Societies, member of the Executive Committee of the Asian Congress of Neurosurgeons, member of the Editorial Board of the European Journal of Neurosurgery “Acta Neurochirurgica”, member of the editorial board of the journal “Pediatric Neurosurgery and Neurology” (Russia), member of the editorial board of the journal “Epilepsy. Paroxysmal States” (Russia), honorary member of the Association of Neurosurgeons of Russia, member of the Academia Eurasiana Neurochirurgica.
REVIEW: «Today, interest in the technology of high–intensity focused ultrasound HIFU therapy is growing all over the world – it is a naive high-tech method of treating oncological diseases. Thanks to the efforts and professional activity of Professor Khamzabayev, this method began to be used in our country. This method has proven to be highly effective in treating patients with malignant and benign pathologies of various localizations. And today more than 1000 patients with good results have been treated in Kazakhstan, which determines the importance and necessity of further development of this technology».
KAPRIN ANDREY DMITRIEVICH
Kaprin Andrey Dmitrievich — Russian scientist, Chief oncologist, Doctor of Medical Sciences, Professor, Academician of the Russian Academy of Sciences, corresponding member of the Russian Academy of Education.General Director of the Federal State Budgetary Institution “National Medical Research Radiological Centre” of the Ministry of Health of the Russian Federation, Director of the P. A. Hetsen Moscow Oncology Research Institute – branch of the Federal State Budgetary Institution ” National Medical Research Radiological Centre” of the Ministry of Health of the Russian Federation.
President of the Association of Oncologists of Russia, President of the Association of Directors of Centers and Institutes of Oncology and Radiology of the CIS and Eurasia. Honored Doctor of the Russian Federation, Laureate of the Award of the Government of the Russian Federation in the field of science and technology “For the development, production and introduction of domestic radio sources for contact radiation therapy in oncology”, Chief external oncologist of the Ministry of Health of the Russian Federation, Head of the Department of the Peoples’ Friendship University of Russia.
REVIEW: «The demonstrated equipment is indeed one of the steps towards progress, an amazing find in the treatment of tumors. The procedures are completely painless, without the use of a knife, without complications in the aftermath. Kazakhstan has outstripped Russia in the field of HIFU therapy, this is a breakthrough and an absolute success. Really modern and advanced equipment, which will certainly improve the quality of life of patients. I think the main thing is to take patients who are difficult to help, it will be well combined with various methods of treatment».
NADEZHDA IVANOVNA ROZHKOVA
Nadezhda Ivanovna Rozhkova – Doctor of Medical Sciences, Professor, Honored Scientist of the Russian Federation, Laureate of the USSR Council of Ministers Award, Head of the National Center of Oncology of Reproductive Organs of the P.A. Hertsen Moscow Oncology Research Institute – branch of the Federal State Budgetary Institution “National Medical Research Radiological Centre” of the Ministry of Health of Russia, Professor of the Department of Clinical Mammology, Radiation Diagnostics and Radiation Therapy of the Faculty of Advanced Training of Medical Workers of the Peoples’ Friendship University of Russia. President of the Russian Association of Mammologists.
REVIEW: «First of all, I would like to say that our medicine is now focused on the development of gentle technologies, the so-called technologies of aesthetic mammology, aesthetic medicine, which is aimed at preserving beauty, and in particular, here is your HIFU technique that you use, a focused ultrasound beam that treats tumors and does not allow it to grow. In my opinion, the technique is excellent, which I liked first of all, that in the end there are similar ones, but this is a special device that does not require a special room, special protection of walls, which are usually used for magnetic resonance imaging, for X-ray machines and so on. This is a very big advantage, that is, it can be used in ordinary premises, and by the way, in particular in private centers, because now they have also received their development and this is very good. The technique is good because it allows, firstly, to treat tumors of different localizations, not only the mammary gland, of course the mammary gland is very important and this is my section, but nevertheless, tumors of other organs and systems and this is very important. So, from the words and from the literature, I know that monitoring has been carried out for more than 5 years, these patients have been treated and there are no relapses, this is a very good indicator. And not only that, during the study, despite the fact that the temperature is high, the tumor is being treated, the woman does not feel any discomfort, that is, they ask her in front of me: how does she feel, she says that she is completely normal, she just feels some kind of heat, there is no heat, no burn is happening here. Computer systems are very well developed here, which clearly focus this beam, exactly where the doctor submits the task. You can even treat large tumors, which of course is not desirable, our common medical traditions must be observed here, that is, surgical treatment has been done and so on, but there are some who do not want to do surgery, they start going to healers and this is very sharply negative, because it leads to advanced forms of cancer, and then it is very difficult for us to treat them. Here we can offer a woman an alternative, that is, she can try this method and in general this method is very effective and efficient. The technique, in my opinion, is extremely good and interesting. It corresponds to the main trends in the development of modern X-ray radiology».
SOLOVOV VYACHESLAV ALEXANDROVICH
Solovov Vyacheslav Alexandrovich — oncologist, professor, Doctor of Medical Sciences. Head of the Department of Interventional methods of Diagnosis and Treatment. Full member of the International Association of Therapeutic Ultrasound, corresponding member of the American Association of Radiologists, Full member of the Association of European and American Medical Oncologists, Awarded the Diploma of the Minister of Health of the Republic of Kazakhstan in 2011 for his contribution to the development of healthcare in Kazakhstan.
REVIEW: «Kazakhstan is very lucky – after all, with the purchase of such a device, they have become one step closer to quality treatment. Ahead of all other CIS countries, Kazakhstani entrepreneurs have taken up the treatment of cancer patients, introducing the latest developments in the world in the fight against cancer. This is a serious step, and we, for our part, will provide the necessary scientific assistance and wish prosperity and successful results».
© 2021 V.A.Solovov, N.Zh.Khamzabaev, V.V. Benberin, 2021
UDC 616-006
HIGH-INTENSITY FOCUSED ULTRASOUND
ABLATION (HIFU) IN THE TREATMENT OF CANCER PATIENTS
V.A.Solovov, N.Zh.Khamzabaev, V.V. Benberin
High-intensity Focused Ultrasound Therapy (HIFU) is a rapidly developing technology that combines the latest developments in medical imaging and high-tech treatment. HIFU therapy is distinguished by a wide range of applications in medicine, high treatment efficiency, minimal number of complications, non-invasiveness, short recovery time. This review provides literature data on the use of ultrasound ablation in the treatment of cancer patients.
Keywords high-intensity focused ultrasound ablation, oncological care.
High-intensity focused ultrasound ablation (HIFU) is a rapidly developing technology that includes modern developments in medical imaging and minimally invasive therapy under visual control. HIFU therapy has high treatment efficiency and accuracy, the absence of ionizing radiation, the possibility of treating cancer at all stages (radical in the early stages, palliative in the advanced ones), the absence of anesthesia, a short rehabilitation period, the possibility of treating cancer of many localizations – prostate, pancreas, liver, kidneys, bones, soft tissues, bladder, retroperitoneal space, mammary and thyroid glands, uterus. The method is not limited only to ultrasound ablation of neoplasms, and is also widely used for palliative purposes to relieve pain of tumor genesis.
The first scientific work devoted to HIFU was published in the 20s of the XX century, in which American researchers Wood and Loomis described the effects of focused ultrasound on unicellular organisms and tissue samples of fish [41]. In 1956, Professor A.K. Burov first proposed the idea of using focused high-frequency sound waves in the treatment of malignant tumors [42]. A group of researchers from the Illinois Institute of Technology, USA, in 1957 described in detail the effects of focused ultrasound on animal tissues, thereby laying the theoretical foundations for the introduction of HIFU into clinical practice. The observations published in 1960 by Soviet scientists L. D. Rosenberg and M. G. Sirotyuk on the emission of sound into a liquid in the presence of cavitation, as well as the development of devices for measuring ultrasonic fields in media in the presence of cavitation, made it possible to make a big step in the development of the method and a general understanding of the physics of ultrasound effects on tissues [52]. The appearance of imaging methods in the doctor’s arsenal made it possible to monitor changes in tissues exposed to HIFU and evaluate the therapeutic effect in real time. The clinical experience accumulated over many years demonstrates the possibility of using high-intensity focused ultrasound ablation in oncological practice, allowed us to evaluate the effectiveness of the technology and side effects, as well as morphological changes in tissues. The principle of HIFU therapy is based on the effect of high-frequency sound waves concentrated in a given focus, generated by a piezoelectric element [40]. Ultrasound waves have a pronounced ability to have a focal effect on tissues, unlike scattered waves used, for example, in ultrasound diagnostics. The cytolytic effect is achieved due to a cascade of processes caused by mechanical and thermal effects of ultrasound. Due to the absorption of acoustic energy by tissues, their local heating occurs up to 850C, and as a result, coagulation necrosis occurs. The most important mechanical factor of the impact is the effect of cavitation – the appearance of microscopic gas cavities, microbubbles in the tissues, during the collapse of which a shock wave is formed, developing a pressure in the microenvironment up to 30,000 Bar, which ensures the physical destruction of cells [43, 44]. The great advantage of HIFU therapy is the ability to monitor the ablation zone using diagnostic ultrasound in real time. In addition to ultrasound navigation, MRI control is also used, which provides better visualization, but has the traditional disadvantages of nuclear magnetic resonance: the high cost of the method and spatial limitations [45, 46].
Therapy of pain syndrome of cancer patients
Pain syndrome is noted in 80% of cancer patients, it is often severe and requires treatment with analgesics [19]. Despite the progress made in the treatment of pain in such patients, modern therapies have limited effectiveness, which significantly worsens the quality of life of patients [18, 19].
Different pain management strategies can be implemented depending on the type and stage of cancer. In general, currently, the standard of pain treatment in cancer patients is treatment with nonsteroidal anti-inflammatory drugs and opioids in accordance with the three-step pain scale of the World Health Organization (WHO) [32]. Morphine is the most commonly used opioid; however, its effectiveness is limited by side effects such as sedation, nausea, constipation and respiratory depression; variability in patient response [22]. In addition, the use and effectiveness of opioids is limited by hyperalgesia caused by them, stimulation of tumor growth and neoangiogenesis and the development of opioid dependence [9, 19, 22, 28].
In the case of insufficient analgesic effect, interventional techniques such as regional anesthesia, nerve blockade and neuroaxial neurolysis, as well as implantable drug delivery systems, can be used in drug treatment. Repeated treatment sessions are often necessary [3]. In some cases, neurosurgical operations are performed to modulate or destroy structures involved in the transmission and perception of pain [29].
Treatments such as radiation therapy, chemotherapy, and surgery can eliminate pain, but they can also make it worse. In addition, neuropathy caused by chemotherapy is observed in 30-70% of patients and often leads to a reduction in the dose of the drug to a suboptimal level and, as a consequence, to inadequate treatment [19].
HIFU therapy of bone metastases
Bone metastases are one of the most common causes of pain in cancer patients [21]. Regardless of the cause – mechanical or biochemical – the pain can be severe and difficult to control.
Currently, the standard of treatment for metastatic bone pain is radiation therapy. However, this method is not effective enough in many cases. It is reported that 20-30% of patients do not experience adequate anesthesia, and a significant number of them have recurrent pain. At the same time, there is a limitation of repeated treatment due to the significant toxic effects of radiation [30]. In most cases, radiation therapy has a long latency period, up to 4 weeks, necessary to achieve a palliative effect in patients with severe pain syndrome [13, 17].
In the last decade, HIFU therapy has been approved for the treatment of bone metastases in the USA, Europe, Asia, Canada, Israel and Russia. In 2015, a consensus was reached by recognized international experts on the effectiveness of the treatment of painful bone metastases by HIFU therapy [12]. There are several mechanisms for pain relief achieved with HIFU. Periosteal denervation caused by heating has the greatest effect on pain relief [4]. Coagulation necrosis of the tumor can lead to a decrease in pain due to a decrease in the size of the tumor [4]. Moreover, the removal of tumor cells reduces the local release of chemical mediators and the degree of osteolysis caused by osteoclasts [37]. Also, HIFU therapy causes bone remodeling with rapid recovery of thermal damage and accelerated sclerosis in osteolytic metastases [2, 5, 8, 14,15, 24,].
Clinical studies of HIFU therapy were conducted under the control of ultrasound [16] and MRI [4, 5, 8, 11, 14, 17, 24], which have demonstrated the high effectiveness of the method for relieving pain syndrome in patients with bone metastases.
Currently, HIFU is recommended as a second-line treatment after radiation therapy to relieve pain associated with bone metastases other than the bones of the skull and spine. HIFU can be used to treat metastases of the ribs, sternum, pelvic bones, shoulder girdle, back of the lumbar and sacral vertebrae and limbs [12].
HIFU can be used as a first-line treatment when radiation therapy is contraindicated or the patient refuses to receive it. The main goal of treatment is analgesia, although local control of the tumor can be assessed as a secondary goal [11]. In 2013, a randomized placebo-controlled blind multicenter HIFU study was conducted with 147 patients. Pain reduction was achieved in 64.3% of patients, and about 20% of them achieved complete anesthesia. In two thirds of patients, the response was achieved within 3 days [13]. In the study Bertrand et al. [1] it is reported that all patients had a significant reduction in pain a week after HIFU. In addition, the study noted that a complete tumor response was achieved in 37.5% of patients, a partial response in 50%. In another study, the authors show that in 53% of patients with bone metastases, pain relief occurred within 30 days after treatment [10].
HIFU has advantages for relieving pain syndrome in patients with bone metastases. There are no restrictions based on the type of bone injury (osteolytic or osteoblastic) associated with previous radiation therapy or chemotherapy. In addition, the number of sessions that a patient can undergo in cases of relapse of pain is not limited [4, 13, 17]. Moreover, HIFU can be performed simultaneously with chemotherapy [23]. Pain syndrome is stopped in 60-100% of patients, is achieved within 3 days and lasts more than 3 months [4, 8, 13, 17, 24].
HIFU Pancreatic Cancer Therapy
Pancreatic adenocarcinoma accounts for more than 95% of all pancreatic cancers and is currently the fourth leading cause of cancer death. Pancreatic cancer is most often detected at an inoperable stage, and only 20% of patients are operable at diagnosis [7]. In addition, after surgery, the frequency of local-regional relapses is high, which explains the high mortality rate. 60-90 % of patients with pancreatic cancer have a pronounced pain syndrome [49].
In a recent meta-analysis, it was shown that the use of HIFU relieves pain syndrome in most patients with pancreatic adenocarcinoma. The mechanisms of action are not fully understood, but they can be based on thermal damage to the nerve endings of the tumor, inactivation of the fibers of the abdominal plexus and a decrease in the volume of the tumor, which leads to a decrease in mechanical pressure on nerve structures. It is noted that HIFU therapy is effective in relieving pain syndrome in 80-100% of patients with pancreatic cancer [7]. The immediate analgesic effect is significant, since most patients can stop taking opioid medications. In another study, the analgesic effect of HIFU therapy was noted for a longer period – up to 17 months [34]. In the study Marinova et al. [20] it is reported that 85% of patients after HIFU achieved long-term relief of pain syndrome, while 50% of patients after treatment did not need any additional analgesics.
In addition to the analgesic effect, a number of authors note local tumor control. It was also noted that pain relief occurs even in the absence of a tumor reaction. Xiong and co-authors [35] inform that the analgesic effect was achieved in 88.0% and 76.2% of patients in both the presence and absence of an objective tumor response, respectively. Similar results were obtained by Zhao et al. [39]: pain relief was achieved in 88.2% of patients with a tumor response in 35.0% of patients with stable or progressive disease. In the work of Ning et al. [25] the results of treatment with HIFU therapy in 523 patients with unresectable pancreatic tumors were published. The authors noted that the majority of patients had complete or partial relief of pain syndrome, as well as an increase in patient survival compared with chemotherapy.
In addition to pain relief, HIFU therapy increases patient survival. A significant increase in survival was observed in an uncontrolled series of cases of patients with pancreatic adenocarcinoma of stage III and IV, who underwent HIFU in conjunction with chemotherapy. The maximum survival after treatment was 3.4 years [31].
HIFU Prostate Cancer Therapy
The main advantages of HIFU in the treatment of prostate cancer are the non-invasiveness of the method, the absence of ionizing radiation, the possibility of use in patients with severe concomitant pathology, good medium and long-term oncological results, the possibility of repeated procedures in one patient and a low percentage of perioperative complications [46]. In addition, an important factor of reproducibility of the method is its low cost and short learning curve of the operator. Chiang P. H., Liu Y. Y. presented a large retrospective study involving 492 patients comparing the main surgical methods of prostate cancer treatment – radical prostatectomy, brachytherapy, cryodestruction and HIFU. The average follow-up period was 3 years. The highest frequency of biochemical relapse after treatment (54.7%) was observed in the brachytherapy group, especially in patients of intermediate and high risk according to D’Amico. The HIFU group demonstrated not only good oncological results, but also satisfactory urine retention function (according to the IPSS questionnaire), and the absence of erectile dysfunction in 65.5% of patients a year after treatment [47]. In 2015, Stephanie Guillaumier and co-authors presented a multicenter study of 5-year results after focal HIFU therapy for localized prostate cancer. The analysis included 625 patients who underwent HIFU therapy, and their rates of relapse-free, metastatic, cancer-specific, and overall survival were 88%, 98%, 100% and 99%. In the same year 2015, a group of British and American researchers led by Mark Emberton published data from a multicenter study involving 754 patients. The average follow-up period was 46 months, while 70% of patients had no biochemical relapse [48]. Mutsuo Hayashi et al. A study of 224 patients with localized prostate cancer was published. There were no prostate cancer deaths among the studied patients. 7-year relapse-free survival among all patients was 75%, and five-year relapse-free survival for patients of low, intermediate and high risk groups was 98%, 84% and 59%, respectively [49]. In 2013, German scientists Ganzer R., Fritsche H. M. described their fourteen-year experience of using HIFU therapy in the treatment of localized prostate cancer. 538 patients were examined, and the average follow-up period was 8.1 years. Overall survival after 5 years was 81%, after 10 years – 61%, cancer-specific survival was 96.7% (death from prostate cancer in 18 patients) [50]. Samara scientists in 2015 presented 7-year results of the use of HIFU in 976 patients with localized prostate cancer. The Kaplan-Meyer relapse-free survival in the entire group of patients was 79.2%, in the low– and medium-risk groups according to D’Amico – 93.9% and 91.8%, respectively [50].
HIFU therapy for other cancers that cause pain syndrome
The possibility of using HIFU therapy to relieve pain in patients with other malignant neoplasms was analyzed. These studies should be taken into account and considered as an option for conducting therapy for pain relief.
Neuroendocrine tumors of the pancreas (NPJ) were effectively treated with HIFU under ultrasound control [6, 26, 27]. Although NTTP are not as aggressive as pancreatic adenocarcinoma, they are often diagnosed late, when most patients have abdominal pain, dyspepsia and insomnia due to pain. The majority of patients noted the disappearance of pain after therapy.
A study was published evaluating HIFU therapy under ultrasound control for the treatment of inoperable hepatocellular carcinoma in 145 patients. Relief of pain syndrome was achieved in 84.8% of patients. In addition, appetite improved in 76.3% of patients and the general well-being of patients. At the same time, survival was higher in patients in the group where HIFU treatment was carried out for the entire volume of the tumor [36].
A group of 83 patients with gastric cancer metastases to abdominal lymph nodes who received chemotherapy in combination with HIFU was compared with 102 patients who were treated with chemotherapy alone. 56 out of 83 patients in the chemotherapy and HIFU group and 64 out of 102 patients in the chemotherapy-only group experienced pain before treatment. Partial or complete pain relief was achieved in 75% of patients in the group receiving HIFU together with chemotherapy and in 51.6% of patients in the group receiving only chemotherapy [38].
Encouraging results were observed in patients with advanced stages of malignant neoplasms of the kidneys. In one study, 13 patients underwent HIFU therapy. After treatment, 90% of patients reported a reduction in pain. In 2 patients, the stage of cancer was lowered, which allowed for radical nephrectomy [33].
The results of these studies are promising, not only because pain relief was successful in most of the treated patients, but also because HIFU therapy demonstrated stable local control of the tumor or led to a decrease in the stage. The noninvasiveness of HIFU therapy makes this treatment available to patients with concomitant diseases who cannot undergo surgery.
Conclusion:
Summarizing the above, it should be noted that HIFU therapy will play an important role in the treatment of cancer patients. Having significant advantages, such as non-invasiveness, high efficiency and accuracy of treatment, rapid and long-term relief of pain syndrome, the minimum number of complications allows the use of HIFU for the treatment of malignant neoplasms of various localizations and stages. In addition, HIFU therapy can be combined with all other types of anti-cancer treatment. HIFU therapy significantly improves the quality of life and leads to an increase in the survival rate of cancer patients.
Literature
JP., Moreau JL. et al. High-intensity focused ultrasound in prostate cancer; a systematic literature review of the French Association of Urology. BJU Int 2008; 101: 1205-13.
